Showing 275 products
Standard cleaning nozzles made of wear-resistant steel, Appropriate for removal of loose rubble stone, gravel, and soft deposits.
6"-12" PIPE SIZE 50 GPM @ 1450PSI MAX 3,6000PSI SPRAY ANGLE 10 AND 30 DEG
*PLEASE CONFIRM YOUR UNITS PRESSURE AND FLOW AT THE TIME OF ORDER*
The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum of Ø 1mm.
Advantages
Applications
The scraper is used where particularly high flushing capacity and a correspondingly good flushing effect are required. Depending on the design, the tool is suitable for channel diameters between 300 and 2,500 mm. During this process, the scraper does not float. It thus ensures excellent basic cleaning even in channels that have a lot of water passing through them.
50.075G, 50.100G, 50.125G
Area of application:
- Pipe diameter of 300 mm - 2500 mm
- Cleaning large quantities of deposits
- Cleaning the bottom of a channel
Concentrated powerful advance by means of 4 front jet nozzles. The sharp edges cut, break and penetrate through every kind of blockage. Made of wear-resistant, hardened steel. All nozzles from art. 60.038 onward are provided with ceramic inserts. Because of this, the efficiency is considerably higher compared with those nozzles with drilled holes and the service life is several times longer.
Applications
enz® Camera – the camera nozzle with integrated data management
1" CONNECTING THREAD
6-16" PIPE RANGE
40 GPM @ 1,500PSI
The enz® Camera Nozzle adds a new dimension to the enz® nozzle product range! The modular design allows universal use with all nozzle types, such as the eBomb or the eBulldog, and thus guarantees streak-free all-around cleaning in every application! The HD-ready resolution and 12 high-power LEDs deliver high-resolution video footage for quality control, documentation, and preliminary inspection. Data management is fully integrated into the system through the WiFi interface and connection to the enz® Cloud. All your manholes and channels are automatically mapped on Google Maps with the videos. The enz® Camera Nozzle, which is simple, fast, and robust, increases productivity without any negative impact on the cleaning performance or quality. The eBomb 1" – 1 1/4" with cage and plastic skids are specially designed for pipes with inliner.
The corresponding app for iOS and Android is available for download.
enz® Camera – the camera nozzle with integrated data management
1" CONNECTING THREAD
8-23" PIPE RANGE
53GPM @ 2500PSI
The enz® Camera Nozzle adds a new dimension to the enz® nozzle product range! The modular design allows universal use with all nozzle types, such as the eBomb or the eBulldog, and thus guarantees streak-free all-around cleaning in every application!
The HD-ready resolution and 12 high-power LEDs deliver high-resolution video footage for quality control, documentation, and preliminary inspection. Data management is fully integrated into the system through the WiFi interface and connection to the enz® Cloud. All your manholes and channels are automatically mapped on Google Maps with the videos. The enz® Camera Nozzle, which is simple, fast, and robust, increases productivity without any negative impact on the cleaning performance or quality.
The corresponding app for iOS and Android is available for download.
This enz® tool is especially suited to clean flat pipes and channels. The flat design combined with the rounded corners and edges provides the tool with ideal gliding properties. Ceramic inserts and an optimized flow reversal create compact and aggressive water jets. The low and compact design facilitates access to a wide variety of pipes and channels.
70.075, 70.100, 70.125
Applications
enz® nozzles with forward impact angle of approx. 45° on the pipe wall as well as a front jet (on request) and 3 retro thrust jets cause a cork-screw-like advance through the clogged pipe. While the front nozzles loosens and the semi-radial nozzles disintegrate the residues, the thrust nozzles are driving the nozzle head forwards and simultaneously pushing the waste material backwards.
Applications
PIPE RANGE 45 for THRUST & FLUSHING 90 to PIPE WALL
This all round enz® combination nozzle is excellent for flushing out pipes as well as adjoining lateral pipes at any angle. It only requires a very small pump capacity and uses 2 radial jets at a 90° angle to the pipe wall and 2 semi-radial retro-jets at a 45° angle. This combination allows both, a forward thrust of the nozzle and simultaneously, a flushing away of the waste material.
04.050A, BS, 04.060
Applications
he enz® KBRV nozzle is provided with 2 semi-radial jets directed forward in an angle of 45°. As a result, this nozzle must either be equipped with extra thrust jets or be mounted on a lance. The forward jets desintegrate most any residue and flush the debris ahead of the nozzle.
Applications
The new impact milling cutter family called IMC can be used with recycling water. Due to a very high impact and the diamond or carbide teeth it’s an excellent nozzle to remove hardest deposits such as concrete and limescale. You can use it with or w/out impact depending on the pipe material. Furthermore you can work in pipes from 100mm – 600mm (4”-24”).
Advantages
• high performance due to high impact
• recycling water | less maintenance
• simple maintenance
• low cost to operate
The radial rotating nozzles enz® are equipped with 4 radial jets of 75° for the pipe cleaning and 3 thrust jets for the advance which at the same time flush away the loosened residues. As a result, pipe ducts of all kinds, even with vertical borings etc., will be cleaned. The moving part of the enz® nozzle rotates at a limited speed. These water jets hit the pipe wall directly with great impact, striking every corner.
Applications
ACCESSORY PART FOR THE ENZ BULLDOZER SCRAPER NOZZLES
0050.0755G, 1005G, 1255G
